CNC ROTARY TABLE

Code No.	UNIT	AH-400
Sindle Hole Diameter	Ømm	160
Spindle Hole	Ømm	Ø50H7 / Ø40
Gear Ratio	rpm	1:90
MAX. Rotation Speed (3000 rpm)	rpm	33.3
Servo Motor	FANUC	α22iF
	MITSUBISHI	HF354
	SIEMENS	1FK7084
MIN. Increment		0.001°
Hydraulic Resource Pneumatic / Hydraulic	kg/cm²	30 (Hydraulic)
Output Torque at Brake	kg/m	260
Indexing Accuracy	sec	20
Repeatability	sec	4
